GENERAL INFORMATION - -
OPTIC AND ILLUMINATING FEATURES - -
Context - Industry, Logistic, Facade, Sport
Optică - Asimetric
Luminaire - LED luminaire with small,mid and high lumen power
Unified Glare Rating - ULOR = 0%
Aplicaţie - Intern / Extern
Lumină ieşire (lm) - 13000
Unique digital code (Datamatrix) - Currently not present
Efficiency
(lm/W) - 130
Culoare - Negru
Culoare Temperatură - 4000 K
Tip sursă de lumină - LED - Neinlocuibil
Color Rendering Index - CRI 80
Puterea sistemului - 100 W
Standard Deviation Colour Matching - SDCM = 5
LED Lifetime - L80B50 (Tq25°) = 89.000h
Photobiological Risk CLASS - RG0
Greutate (Kg) - 3.9
Standard - -
Garanţie - 5 ani
ELETRICAL AND LIGHTING FEATURES - -
Temperatură de stocare - -40° +80°
Tensiune de alimentare - 220-240 V
Operating temperature - -30° +50°
Frecvenţă nominală (Hz) - 50 / 60
MATERIALS - -
Driver - Included
Body - Aluminiu turnat
Driver failure rate - F05 = 83.500h Tq 25°
C
Ecran - Flat silked tempered glass 4mm thick with Gewiss logo
Overvoltage protection - Overvoltage protection 6-4kV
OPTIC - With high efficiency OPTIC system
Control System - DALI
Gasket - -
INSTALLATION AND MAINTENANCE - -
Locking Hook - -
Mouting and installation - Ceiling - Wall - Floor
External screw - Oţel
Tilt - With adjustable bracket assembled
Colour - Powder coating
Wiring - With power cable
STA.
