Caracteristici tehnice
Montaj incastrat distribution cabinets
Box for masonry or dry partitions (with dry partitions kit Cat.
No 4 017 24)
Furnizat cu:
removable chassis with rails fitted
reversible door (door + faceplate for 1-row cabinets)
removable faceplates for each row (for 2, 3 and 4-row cabinets)
IP 2X screw terminal blocks
blanking plates (5 module, separable per module or 1/2 module, for 2, 3 and 4-row cabinets)
Spacing between rails 150 mm
Door opening : 180°
Can be equipped with lock and key n° 850 Cat.
No 0 019 66
18 module per row with white door RAL 9003
With earth terminal blocks
Number of rows : 3
Numar de module : 54
Height : 606 mm
Width : 436 mm
Depth : 91 mm
Caracteristici generale
Montaj incastrat cabinets Practibox³ - from 8 to 72 module
Class II
IP 40 - IK 07 with door
Self-extinguishing: resistance to incandescent wire 850 °
C
Conform to IEC 60670-24 and IEC 62208 : allows to achieve assemblies conform to IEC 61439-3.
