Certified lighting for wine, beer and champagne cellars
Single-part IP66 / IP69K extruded polycarbonate profile
Specific amber LED with very narrow spectrum.
PWIS-free to guarantee a perfect finish in paint shops and coating areas.
Quick and safe mounting with no tools needed.
Certified by the Champagne Comitee
Downloads
Features
Mechanical
Profile Extruded polycarbonate with UV protection, upper part grey RAL 7035, bottom part opal
End caps Injected polycarbonate
Gasket PWISS-free silicone
Cable entry Cable gland
Fixing clips Stainless steel
Operational Data
Light colour 0 Custom.
U0
Luminous flux 2,400 lm
Power 68 W
Efficiency 35 lm/W
Functional
Lifetime L80 50,000 h at 25°
C
Fire protection PC / Flammability (UL94): V2
Glow wire test (EN 60695-2-11): 850º
C
Electrical
Driver non dimmable
Connection Terminal block and Cable gland
Flicker factor < 1%
Power factor > 0.95 full load
Photometrical
Dimensions
Length (X) 1,213 mm
Distance between springs (Xm) 800 mm
Width (Y) 76 mm
Height (Z) 67 mm
Weight 1.8 kg
