The Ultimate Template and Layout Pattern Book for Pipefitters and Welders - R. L. (bulldog) Eisenbarth

Descriere YEO:

The Ultimate Template and Layout - Disponibil la libris.ro

Pe YEO găsești The Ultimate Template and Layout de la R. L. (Bulldog) Eisenbarth, în categoria Reference.

Indiferent de nevoile tale, The Ultimate Template and Layout Pattern Book for Pipefitters and Welders - R. L. (bulldog) Eisenbarth din categoria Reference îți poate aduce un echilibru perfect între calitate și preț, cu avantaje practice și moderne.

Preț: 309.69 Lei

Caracteristicile produsului The Ultimate Template and Layout

• Brand: R. L. (Bulldog) Eisenbarth
• Categoria: Reference
• Magazin: libris.ro
• Ultima actualizare: 15-12-2024 01:42:32

Comandă The Ultimate Template and Layout Online, Simplu și Rapid

Prin intermediul platformei YEO, poți comanda The Ultimate Template and Layout de la libris.ro rapid și în siguranță. Bucură-te de o experiență de cumpărături online optimizată și descoperă cele mai bune oferte actualizate constant.

Descriere magazin:
This book was created with over (10,000) formulas worked out to create over (1,600) pipe templates to simplify the everyday task of pipe layout and fabrication for pipefitters and welders. In this book you will find pipe templates for the following. Concentric LR 90 degree base ell supports for (1 1/2 pipe on 1 1/2 pipe) through (24 pipe on 48 pipe.) Dummy leg supports laying flat on 90 degree ells (1 1/2 pipe on 2 pipe) through (14 pipe on 48 pipe.) Eccentric LR 90 degree base ell supports (1 1/2 pipe on 2 pipe) through (24 pipe on 48 pipe.) Eccentric throat level LR 90 degree base ell support (1 1/2 pipe on 2 pipe) through (24 pipe on 48 pipe.) 22 1/2 degree lateral through 60 degree lateral (1 1/2 pipe on 1 1/2 pipe) through (24 pipe on 48 pipe.) 7 1/2 degree miters through 45 degree miters (1 1/2 pipe) through (48 pipe) Orange peel head (2 pipe) through (24 pipe) Concentric reducers (3 x 2) through (24 x 22) Eccentric reducers (3 x 2) through (24 x 22) 90 degree concentric saddle tee (1 1/2 pipe on 1 1/2 pipe) through (42 pipe on 48 pipe) 90 degree eccentric saddle tee (1 1/2 pipe on 2 pipe) through (42 pipe on 48 pipe) This book also includes pipe information on decimal equivalents charts, decimal of a foot chart, fitting to fitting make-up dimension chart, formula\'s for center line dimensions of trimmed elbows, chart for length and spacing dimensions for nozzles with and without reinforcing pads, multiplier constants, pipe circumference chart, pipe data charts by schedule and weights and wall thickness and weights, formula\'s for solving known and unknown angles, chart for dimensions of span distance for dummy legs, standard valve dimensions chart and trigonometric formula tables.
